Key Features

One Clamp to test both PC and APC (8 angle) multiple fiber cores as example of MTP/MTRJ/MPO etc.

Magnification/Resolution in 400×/0.5um or 200×/0.75um.

Smooth focus control,simple operation, stable testing results.

X/Y-axia adjustment for both horizontal and vertical control,broaden the view of field and stabilize image always in central.

HD 8/10.4 Inch LED Display for distinct and clear image shown.

Average light spot in display gets feature of same resolution betweem fiber core and ceramic end face with little testing errors.

Optional USB digital function to connect PC.
