简单描述：

200GHz DWDM 波分复用 4/8/16=Channel

详细介绍：

200GHz DWDM Module 4/8/16=Channel

 29-1 DWDM 副本.jpg

Features

200GHz Channel Spacing

Low Insersion Loss

High Stability



Applications

CATV Links

DWDM Systems

SONET/SDH



Parameters

200GHz DWDM   Module

Number of   Channels

4Ch        8Ch        16Ch

Central   Wavelengths(λс)(nm)

1529.55~1560.61

Channel Spacing

200GHz

Channel   Passband(nm)

λс±0.25

Insertion   Loss(dB)

4Ch

≤2.0

8Ch

≤3.0

16Ch

≤4.0

Isolation(dB)

Adjacent Channel

＞30

Non-Adjacent   Channel

＞40

Passband   Ripple(dB)

≤0.5

Polarization   Dependent Loss(dB)

＜0.2

Polarization   Mode Dispersion(ps)

＜0.2

Return Loss(dB)

＞45

Directivity(dB)

＞50

Maximum Optical   Power(mw)

500

Operating   Temperature(℃)

0~+70

Storage   Temperature

-40~+85

Package   Dimension (mm)ABS Box

                100*80*10         120*80*18

LGX Box

1U/2U/4U   available

19"Rackmount

1U/2U available

Pigtail Length

1.0 meter

*All values   specified are without connectors,Connectors can be supplied on request

*Fiber types   SMF-28 unless otherwise specified






Ordering   Information

DWDM

xxx

xx

xx

xx

xx

x

DWDM

Spacing

Channel

ITU Channel

Fiber Jacket

Fiber Length

Connector

200GHz

04=4Ch

21=21Ch

01=900um

10=1.0m

1=SC/APC

08=8Ch

…

02=2.0um

12=1.2m

2=LC/UPC

16=16Ch

59=59Ch

03=3.0mm

15=1.5m

3=FC/APC
