简单描述：
TPR-586 光纤识别仪
详细介绍：
Support to detect optical signals without disrupting traffic;
Based on non-destructive technology;
Indicate the signal direction in fiber;
Detect a variety of optical tones,
270Hz, 1kHz and 2kHz;
Suitable for 0.25mm, 0.9mm, 3.0mm fiber, and no need to replace the clamp block, more convenient than others;
Build in visible fault locator 1mW or 10mW optional Battery low indication;
Powered by 2 units of 1.5V AA alkaline batteries;
Main Characteristic
Wavelength Range | 900 to 1700nm (SM) | LED Indicator | Signal direction; signal frequency (2kHz/1kHz/270Hz); low battery | |
Recognizable signal type | CW, 2kHz, 1kHz, 270Hz ±10% | Signal intensity | 0 ~ 40 | |
Detector Type | InGaAs 2pcs | Storage Temperature | -20 -- +70 ℃ | |
Fiber Type | 0.9, 0.25, 2.5 mm fiber | Operating Temperature | -10 -- +60 ℃ | |
Sensitivity | 1310 nm | +10dB to -20 dBm (Continuous Wave) | Relative Humidity | < 95% |
+10dB to -15 dBm (Modulated Signal) | Power Supply | AA * 2 | ||
1550 nm | +10dB to -30 dBm (Continuous Wave) | Size | 230mm * 45mm * 45mm | |
+10dB to -25 dBm (Modulated Signal) | Weight | About 200g | ||
