Instrument output light source wavelength

850/1310/1550nm

Optical return loss test

Working wavelength

1310/1550nm

Test range

0~75dB

Wavelength calibration

1310/1550nm

Test accuracy

0.25dB

Stability of the output

0.02dB /hour（@250C)

The interface type

FC/APC

Optical insertion loss test

Wavelength calibration

850/1300/1310/1490/1550/1625nm

Test range

3~80dB

Test accuracy

0.01dB

Display resolution

Logarithmic: 0.001 dB; Linear: nW/mu W / 0.001 mW

Test mode

The linear and nonlinear

The interface type

Interface: FC/SC/ST/general general Φ 2.5 mm / 2.5 mm,Adapter

Total indicator

power

AC 90-260V

Working environment temperature

-50C~+550C

Appearance of the size
