Overview

TPR1600D-MINI is a low cost EPON OLT product, it is 1U height, and can be expanded into 19 inch rack mount products by hanging ears. The features of the OLT are small, convenient, flexible, easy to deploy. It is appropriate to be deployed in compact room environment.The OLTs can be used for “Triple-Play”,VPN, IP Camera, Enterprise LAN and ICT applications.

The TPR1600D-MINI  provide 4 GE interface for uplink, and 4 EPON ports for downstream. It can support 256 ONU under 1:64 splitter ratio.

Each uplink port is connected to a EPON port directly, each PON port behaves as an independent, that EPON OLT port and there is no traffic switching between PON Ports and each PON port forwards packets to and receive packets from one dedicated uplink port.

TPR1600D-MINI provides the full management functions for onu according to CTC standard, Each of the 4 EPON OLT ports is fully compliant with IEEE 802.3ah standard and CTC 2.1specification for SerDes, PCS, FEC, MAC, MPCP State Machines, and OAM extension implementation. Both upstream and downstream are operational at 1.25 Gbps data rates.

Features

• Small Size and Cost Effective OLT

• Fast ONU Register

• Credit Time Control

• Support ONU auto-discovery/auto-configuration/remote upgrade of firmware

• WEB/CLI/EMS Management
