scope of application

φ2 mm/φ3 mm indoorcable

Fiber Diameter

125μm ( 652& 657 )

Cladding Diameter

900μm

Suitable mode

Singlemode&multimode

operating time

about 120s (not including operate fiber time)

Insertion loss (dB)

≤ 0.3dB (1310nm &   1550nm)

Return loss(dB)

≤ -40dB

Bare fiber force

>5 N

Cladding layer force

>10 N

tensile strength

>50 N

Operating temperature

-40~+75℃

Online decoration test (20 N)

 IL ≤ 0.2dB △ RL ≤ 5dB

:Mechanical Endurance (500 times)

 IL ≤ 0.2dB △ RL ≤ 5dB

Frustrated test(4cm high the cement

 IL ≤ 0.2dB △ RL ≤ 5dB

 ground every direction 1 time ,in   total 3 times)
