Description:

MTRJ Patchcord

Details:


MTRJ Patchcord

  18-1 MTRJ 光纤跳线 副本.jpg

Description

Fiber Optic FC patch cord & pigtail,

G652D, single mode or multi mode,

Simplex or duplex, 0.9mm or 2.0mm or 3.0mm cable (PVC/LSZH), length is specified.



Application

* Optical fiber communication system;

* Optical fiber data transmission;

* Optical fiber CATV;

*Optical fiber sensors;

*Local area network (LAN);



  Features

* Low insertion loss;

* Good repeatability;

* Good interchangeability;

* High temperature stability;



 Parameter

Item

  Unit

 Specification

SM

MM

MTRJ/PC

MTRJ/PC

Insertion Loss

dB

≦0.50

≦0.40

Return Loss

dB

35


Operation   Temperature

℃

-25 ~ +75

Storage   Temperature

℃

-25 ~ +75

Fiber   Type

um

9/125

50/125, 62.5/125

Core   Number


Simplex   or Duplex

Durability


﹥1000 times

Industry   Standard


TIA-568A
