Application

3.0 x 2.0 mm butterfly drop cable

Cladding Diameter

125μm ( 657A & 657B )

Coating Diameter

250μm

Insertion Loss

≤ 0.3dB（1310nm & 1550nm）

Reflection Loss

> 50dB

Rate of success

>95%

Clamping Force

>5 N

Tension

>20 N

Temperature Range

-40～+75℃

Tension Test when installed (20 N)

△ IL ≤ 0.2dB △ RL ≤ 5dB

Mechanical Endurance (500 times)

△ IL ≤ 0.2dB △ RL ≤ 5dB

Fall-down Test (4 meters height, 3 time   each direction)

△ IL ≤ 0.2dB △ RL ≤ 5dB
