Main Features
5 inches high Resolution colorful LCD display, image can be turned according to position.
Average splice time: 10 second
TPR-0401
Key Features
One Clamp to test both PC and APC (8 angle) multiple fiber cores as
example of MTP/MTRJ/MPO etc.
Magnification/Resolution in 400×/0.5um or 200×/0.75um.
Smooth focus control,simple operation, stable testing results.
X/Y-axia adjustment for both horizontal and vertical control,broaden
the view of field and stabilize image always in central.
HD 8/10.4 Inch LED Display for distinct and clear image shown.
Average light spot in display gets feature of same resolution betweem
fiber core and ceramic end face with little testing errors.
Optional USB digital function to connect PC.
