Loose tube dia./number   of tube

Ф1.8-Ф4.0 mm/12

Fiber loose tube   pay-off reel size

PN630~PN800

Structure speed

100m/min

Take-up reel size

PN1250~PN1800

Cable-making speed   ( banding pitch=30mm)

80m/min.

CSM pay-off tension

50N~300N

(stranding   pitch=65)

Take-up tension

50N~150N

Cable-making   pitch(single spiral)

60~1000mm±5mm

Accuracy of the counter

0.20%

SZ stranding angle

±4л~±18л

Additional   attenuation

 max.0.02dB/km(SM fiber)

SZ stranding head   speed (max)

1600rpm

Operation direction

Appointment by user

Binding head speed   max.

3500rpm

Overall dimension   of the equipment

42m×4m×3.6m

Binding head   working speed

3000rpm

Installed power

80kw

Binding pitch

20-50mm

Total weigh

16T (approximately)
