Description:

Armored Cable > TF-FO-02

Details:

Armored Cable > TF-FO-02






Products Description



Features:

1.od mechanical property and environment property

2.ame resistant performance

3.ft, agility, convenience for connection

4.tisfy various request of markets and customer



Applications:

Pig tails and Patch cord

Ideal for use in optical device, equipment

Ideal for use in optical distribution frame



Specifications:

Item

Units

Single Mode

Multimode



Core/Mode



μm

9.2±0.4μm@1310nm

50±2.5μm

62.5±2.5μm

Diameter

10.4±0.8μm@1550nm

Cladding Diameter

μm

125±1μm

125±1μm

125±1μm

Max. Attenuation

dB/km

0.4dB/km@1310nm

3.5dB/km@850nm

3.5dB/km@850nm

0.3dB/km@1550nm

1.5dB/km@1300nm

1.5dB/km@1300nm

Operating temperature

℃

-40℃~+85℃

Outer diameter

mm

5.7±0.10mm(duplex)／3.2±0.10mm(one tube and two fibers)

Net weight

kg/km

38/20

Allowable bending radius

（mm）

25

Allowable tensile

（N）

200
