XINYI-17 Technical Polisher

Product Overview

Exceeds requirements for GR-326 End Face Geometry. Uses the Seikoh Giken Patented rotation & revolution method. New I.P.C. holder technology yields the best results in the.industry. No variability in result when polishing 1 or 20 connectors. Polishes up to 24 connectors MU & LC & 20 for SC,FC, & ST. Efficient and fast processes for all connector types. Built  high quality, heat-treated, stainless steel for amazing.precision and durability.Applicable Conn.: FC,SC,ST, LC, MU, D4, E2000(H&S),MTP,MT-RJ.8 deg. or 0 deg.Polishing Time:2.5 min. (quick assembly type).4-5 min. (Standard connectors). Weight:23.5Kg. Dimensions:2 30x230x255mm (small footprint advantage).Power:100-120VAC, 50/60Hz or 220-240VAC 50/60Hz.Motor Speed:70rpm revolution, 1rpm rotation.Plate Material:Heat-treated, Stainless SteelFilm size:3” Polishing Method: Rotation & Revolution (Patent # 4979334).Timer:1 timer (up to 30 min.).
