Function :

For measurement of Optical Connector:

⦁Radius of Curvature

⦁Apex Offset

⦁Fiber Undercut

⦁APC Angle

⦁APC Key Angle

Value-Added:

⦁Concentricity, Ferrule Hole Diameter

⦁Roughness, Scratch Depth Statistic

⦁Sphericity

⦁Polish-Area-Ratio

⦁CpK, Yield Lost

⦁Distance btw two points pickup at 3D surface

Characteristic :

⦁High Accuracy, Reliability, Stability

⦁High Efficiency, scan cycle time around 1 sec

⦁Auto statistic of CpK & yield lost

⦁Additional 6 value-added measurement to expand quality evaluation

⦁Guide operator to optimize polish process

⦁Foot-switch to trigger scan for ease of hand movement

⦁Connect interferometers to net for remote monitor

⦁Barcode Scan & Label Print

⦁Immediate & professional local service

Specification :
